8600 series

TRACTOR SERIES

These new generation tractors are a perfect blend of modern styling and high Performance.

8600 series

TRACTOR SERIES

Tough Efficient Effortless-1

NO.1

Tractor Company in the world
by volume.

Mahindra 8600 tractor Series-3

IDEAL FOR

LIVESTOCK

Mahindra Tractors

DAIRY

Mahindra Tractors

LIVESTOCK

DAIRY

HAY & FORAGE

DRY LAND FARMING

HAULAGE

FEATURES

Group 19895
Group 19895

Dedicated to Southern African Farms

These tractors are specially made for dryland farming & livestock, dairy applications.

Kg icon

5,000 Kg

LIFT CAPACITY

left right icon

4400 cc

DISPLACEMENT

icon - 1

110 Hp

PEAK POWER

Mahindra 8600 Series Tractor-1

Highly fuel efficient

Saves 3000 Litres in 1 Year

They come with tried & tested well known Perkins 4 Cylinder, turbocharged intercooler engine and ZF transmission to offer a formidable combination of power and versatility.

ENGINE

18.2 % Back-Up Torque.
416 Nm Torque @ 1400 Rpm.
16F / 16 R ZF Transmission.

BEST IN CLASS

Independent Four Speed,
Electrohydraulic Actuation,
Mechanical Control, (430 / 540 / 540e / 1000)

MODELS IN THE 8600 SERIES

86-110 P

Mahindra 86-110 P Tractor

ENGINE OUTPUT

83.0 KW

PTO HP

---

CYLINDER

4

WEIGHT

4950 kg

LIFT CAPACITY

5000 kg

TRANSMISSION

Power shift
Hi-Lo

Know everything about
the 8600 series

SPECIFICATION

ENGINE86-110 P
EMISSIONSStage III-B (Interim Tier 4)
MODELPERKINS 1104D-44TA Turbocharged & Intercooled
POWER110 HP @ 2200 RPM
PTO POWER85% of Engine Power
MAX SPEED2400 RPM
TORQUE416Nm @ 1400 RPM
ASPIRATIONTurbocharged, Intercooled
AIR FILTERDry Tape With Pre-Internal Filter
BORE X STROKE99 mm x 110 mm
CYLINDERS4
CYLINDERS-CUBIC CAPACITY (CC)4400 cc
CLUTCH
TYPEDuel
TRANSMISSION
TYPEPower Shift Hi-Lo
NUMBER OF GEARS / SPEEDS16 Forward & 16 Reverse
PTO SHAFT
TYPEIndependent Electro Hydrailic
SPEED540-540E
HYDRAULICS
TYPEElectronical
THREE POINT LINKAGECat II
CONTROLElectro-Hydraulic
LIFT CAPACITY5000 Kg
REAR AUXILARY REMOTE VALVES4 Spool
OTHER
DRIVE SYSTEM4WD
STEERINGHydrostatic Power Steering
BRAKE TYPEOil Immersed Brake
ELECTRICAL
BATTERY CAPACITY12V, 115Ah
ALTERNATOR120 A
DIMENSIONS
LENGTH4455 mm
WHEELBASE2405 mm
WIDTH2030 mm

UNIQUE SELLING POINT

TOUGH

The Perkins 4 cylinder 1104D- 44T turbocharged intercooler engine in these tractors offer an unmatched combination of best-in-class engine power, fuel efficiency and reliability. They are designed to offer maximized torque levels as high as 416 Nm at a low Rpm of 1400 that ensures high productivity in both PTO and draft applications.
The tractor comes with 4 sets of remote standard auxiliary valves giving it the ability to work with different heavy hydraulic implements. The hydraulics operate at a high pressure of 190Mpa & allow heavy loads up to 5000 kg to be lifted. The Automatic Lifting System (ALS) may be controlled mechanically or electrically. ALS is generally used to lift the equipment at the end of the groove while ploughing without changing the settings of hydraulic control levers, and to lower the equipment to the previous setting providing the same ploughing depth at every position in the field. The ALS is used to operate equipment such as a trailer, loader, excavator,rotary plough, etc.

EFFICIENT

The Low rated engine speed ensures lower fuel consumption and less wear and tear of engine components.
The independent PTO lever offer ease in engagement & disengagement during all PTO-driven applications ensuring economy speeds for efficient operation with a variety of implements.
The four-wheel-drive lever locking mechanism is activated with a lever in this model. It is performed electronically. Four-wheel drive may be activated or deactivated at all gear ranges, at fixed and low speeds that the tractor moves. Four-wheel drive shall be activated so that you can obtain maximum efficiency from your tractor in rough terrain conditions. Slipping is reduced and the service life of tires is increased when the four-wheel drive is activated for tires that slip with a two-wheel drive.

EFFORTLESS

It comes with numerous features & options to assure you a comfortable working experience. Built-in air compressor system for tyre inflation, air trailer brake, 2-way adjustable operator seats ensures superior comfort & steering. The easy access to all controls & levers & illumination at 8 different locations ensure the comfort & convenience of the operator. With sufficient ground clearance of 520 mm, it is suitable to work on uneven surfaces. Radio / CD Player, an air-conditioned cabin / Heater and ventilation system are standard. Another standout feature is the Height & tilt adjustable cabin. Lastly, the electronic push-button activated PTO offer ease in engagement & disengagement during all PTO-driven applications.

The ZF T-557 L transmission provides smooth shifting on the move. The standard 16F+16R speeds maximize performance in different applications & terrain. It allows the tractor to work in a wide range of speeds from 2.20 to 39.30 km/hour. It comes with a Power Shift & button activated Differential Lock. It also has a dry mechanically controlled clutch with large 12” Cerametallic plates for longer life. The forward/reverse shuttle shuttle (4WD) makes shifting between forward and reverse smooth and quick, thereby ensuring maximum productivity during intense loader and headland operations. The Synchromesh heavy-duty transmission is extremely reliable and easy to use. It eliminates the need to depress the clutch every time the tractor needs to change direction, forward or reverse and the high number of speeds options allows performing a broad range of farming applications most efficiently.
